光源
|
卤钨灯 (6700)
氙 (6705/6715)
|
光学系统
|
Sealed, MgF coated, split beam
|
波长范围
|
320-1100nm (6700) 190-1100nm (6705/6715)
|
波长分辨率
|
0.1nm
|
波长精度
|
±1.0nm
|
波长重现性
|
±0.2nm
|
光谱带宽
|
4nm (6700/6705) 1.5nm (6715)
|
杂光
|
<0.1 at 340nm (6700) <0.05 at 220nm (6705/6715)
|
测光范围
|
-0.300 to 3.000A & 0 to 199.9%T
|
测光分辨率
|
0.001A & 0.1%T
|
测光精度
|
±0.005 at 1A
|
测光稳定性
|
< 0.001A per hour
|
定量范围
|
-99999 to +99999
|
标准数量
|
20 with up to 5 replicates of each
|
曲线拟合算法
|
Linear, Quadratic and Cubic functions
|
多波长数据点
|
Up to 4 wavelengths
|
计算值
|
Difference and ratio
|
Kinetics时限
|
0 to 9999 seconds
|
Kinetics 校验
|
Standard or Factor
|
扫描速度
|
1500nm/minute at 0.1nm data steps
|
后扫描分析
|
Peak/Valley pick, Peak Ratios, Area, Zoom,
Wavelength Table, Derivatives, Smoothing
|
配置
|
Secure multi-user and Free Access
|
用户数量
|
10 + Supervisor
|
方法数量
|
>1000 (on internal flash memory or removable media
|
结果储存
|
>1000 (on internal flash memory or removable media
|
移动媒体
|
MM/SD memory card or SD/USB memory card
|
接口
|
USB, Centronics, Analogue
|
PC软件
|
Supplied on CD-ROM with USB interface cable
|
电源
|
100 to 230V ac / 50 or 60Hz
|
样品室
|
150mm (max. height) x 130mm (w) x 210mm (d)
|
尺寸
|
490 x 390 x 220mm
|
重量
|
7.5 Kg
|
